230W Moving Head Light

HL-MB230

230W Moving Head Light

分类 Beam, Moving Head Lights 标签 Architectural / Indoor, Beam, Concert / Touring, Events

230W Moving Head Light with an extended 2,000-hour life span, produces a straight, sharp 2˚ beam in any application, making it a cost-saving investment.

Digital position correction technology offers fast and smooth movement. A wide range of mid-air effects is achievable via static gobo wheel (16 gobos) and color wheel (14 colors) in conjunction with two rotating 8- or 24-facet prisms.

The fixture’s compact housing makes it suitable for multiple applications, including events, installations, TV shows, and rentals.

Features

Diameter of lens: 152mm
Long-lifedesign:2,000 hour lamp life, with sleep mode&instant wake-up
Color temperature: 8000K
Macro effect and half-tone effect
1x static gobo wheel with 16 gobos plus open
1x color wheel with 14 colors plus open
2x prisms: dual 8- and 24-facet prisms, rotatable in both directions and overlay table
Beam angle: 1-3.8°
Frost: Can be used independently
Motorized focus
Outstanding strobe effect with variable speed
Smooth dimming from 0-100%
Flicker-free management
Dust-proof and oil-proof design

其他信息

Light Source

Light Source: 230W discharge lamp
Life expectancy: 2,000 hours

Optical System

The advanced optical system ensures clear, sharp image quality
High-efficiency optical system
Beam angle: 2°

Control & Program

4-button touch panel
Display: Color display
Protocols: DMX512,Master/Slave
DMX Modes: 2
Control channels: 16, 20
Pan/Tilt resolution: 16-bit
Electronic ballast

PAN & TILT

Pan movement: 540°
Tilt movement: 270°
Automatic Pan/Tilt position correction

Static Gobos

1x static gobo wheel with 16 gobos plus open

Color Wheel

1x color wheel with 14 colors plus white

Electrical & Connectors

Power supply with electronic auto-ranging
Input voltage range: AC 100-240V, 50/60Hz
Power consumption: 320W
Power cord out
Data in/out: 3-pin XLR

Fixture Specification

Height: 565mm (22.2”)
Width: 350mm (13.8”)
Depth: 253mm (10.0”)
Weight: 17kg (39.7lb)

Work environment

Maximum ambient temperature: 40°C
Maximum surface temperature: 65°C
Minimum operating temperature: 0°C

Approvals

CE compliant

Installation

Horizontal or vertical mounting
The operating position is universal
2 pairs of 1/4-turn locking points under the base
2x fast-lock clamps with 1/4-turn locks for 50mm truss
Safety cable attachment point

Included items

User Manual
Power Cable
2x clamps with 1/4-turn locks for 50mm truss
Signal line: 3-pin signal line

Optional Accessories (with item code)

Raincover:
Clamp:
Safety cable:
Signal line: 3-pin signal line
