HL-ML2512 25PCS LED Matrix Light

Name: HL-ML2512 25PCS LED Matrix Light
Brand: KALE LIGHTING
Price: 1 USD
Availability: InStock

HL-ML2512

分类 Effects, Moving Head Lights

25PCS LED Matrix Light individual control of each RGBA pixel. With a circular reflector mirror, can create a mirrorball effect with beam light spotting on the mirror. Equipped with an electronic linear zoom system, the zoom range is 10°~60°, and the color is stable and uniform in the dimming range, easy to create a wonderful dynamic world. Outstanding strobe effect with variable speed, 0-100% smooth dimming, to meet the washing effect of wider applications.

Features

Light source: 25x12W RGBA LED
With powerful beam and wash effects
Individual control of each RGBA pixel
The outstanding color macro effect
Electronic linear zoom system
With circular reflector mirror, can create a mirrorball effect with beam light spotting on the mirror
Outstanding strobe effect with variable speed
0~100% smooth dimming
Fast and mute operating
Flicker-free management
Dust-proof and oil-proof design

Product Price：$1.00

其他信息

Light source

Light source: 25x12W RGBA LED
LED life expectancy: 20000 hours

Optical system

The advanced optical system to ensure the clear and large-range beam
effect
High-efficiency zoom optical system, ratio 1:6

Control and Program

4-buttons
Display: LCD display
Protocols: DMX512
DMX Protocol modes: 4
Control channels: 16,37,112
Pan/Tilt Resolution: 16 bit
Dimmer: 16 bit

PAN & TILT

Pan movement: 540°
Tilt movement: 240°
Automatic Pan/Tilt position correction

Electrical and Connectors

Power supply with electronic auto-ranging
Input voltage range: AC 100-240 V, 50/60 Hz
Power consumption: 4000 W
Power Connector input
Data in/out: 3-pin XLR

Fixture Specification

Height: 500 mm
Width: 470 mm
Depth: 380 mm
Weight: 14 kg

Work Environment

Maximum ambient temperature: 40°C
Maximum surface temperature: 65°C
Minimum operating temperature: 0°C

Approvals

CE Compliant

Installation

Horizontally or vertically mounting are available
The operating position is universal
2 pairs of 1/4-turn locking points under the base
2 x fast-locked clamps with 1/4-turn locks for 50-millimeter truss
Safety cable attachment point

Included Items

Circular reflector mirror
User Manual
Power Cable
2 pairs of 1/4-turn locking points under the base

Optional Accessories (with item code)

Clamps：
Signal Line：3-pin signal line
Safety cable :

HL-ML2512
