HL-ML200BS 200W LED Spot Moving Head Light

HL-ML200BS

HL-ML200BS 200W LED Spot Moving Head Light

分类 Moving Head Lights, Spot

HL-ML200BS 200W LED Beam&Spot Moving Head Light is small and portable, with powerful light output, energy-saving, and environmental protection integrating powerful beam and washing functions. Adopts 200W LED, individual control of each RGBA pixel. A circular reflector mirror can create a mirrorball effect with beam light spotting on the mirror. Equipped with an electronic linear zoom system, the zoom range is 8°~15°, and the color is stable and uniform in the dimming range, easy to create a wonderful dynamic world. Outstanding strobe effect with variable speed, 0-100% smooth dimming, to meet the washing effect of wider applications.

Features

Light source: 200W High power LED
Power consumption:240W
Color wheel: one color wheel,7kinds of color chips in one color wheel
Static Gobo:8gobos
Rotation Gobo:6gobos
Electronic linear zoom system
Zoom range: 8°~15°
0~100% smooth dimming
Fast and mute operating
Flicker-free management
Dust-proof and oil-proof design

Product Price：$1.00

其他信息





Light source

Light source: 200W High power LED
LED life expectancy: 20000 hours

Optical system

The advanced optical system ensures a clear and large-range beam & wash effect
High-efficiency zoom optical system, ratio 1:6
Zoom range: 8° – 15°

Control and Program

4-buttons
Display: LCD display
Protocols: DMX512
Control mode: DMX512 /master-Slave/Autorun
Control channels: 6,18
Pan/Tilt Resolution: 16 bit
Dimmer: 16 bit

PAN & TILT

Pan movement: 540°
Tilt movement: 240°
Automatic Pan/Tilt position correction

Electrical and Connectors

Power supply with electronic auto-ranging
Input voltage range: AC 100-240 V, 50/60 Hz
Power consumption: 260 W
Power Connector input
Data in/out: 3-pin XLR

Fixture Specification

Height: 475 mm
Width: 355 mm
Depth: 380 mm
Weight: 13 kg

Work Environment

Maximum ambient temperature: 40°C
Maximum surface temperature: 65°C
Minimum operating temperature: 0°C

Approvals

CE Compliant

Installation

Horizontally or vertically mounting are available
The operating position is universal
2 pairs of 1/4-turn locking points under the base
2 x fast-locked clamps with 1/4-turn locks for 50-millimeter truss
Safety cable attachment point

HL-ML200BS
